How To Install Whirlpool Dishwasher - PartsIPS


Whirlpool dishwasher installation involves connecting water lines, electric lines connection, leveling your unit and running operating tests to ensure the dishwasher functioning properly. If you have bought a new Whirlpool dishwasher and thinking about how to install it, this guide helps you with a general outline for installation. Check the steps below on how to install Whirlpool dishwasher to complete your task easier.

How to Install Whirlpool Dishwasher?

If you are new to installing a dishwasher, it may take up to two hours to complete. It's good to have the assistance of at least one other person for lifting and tilting the machine during installation. Moreover, you should follow your local codes for electric connections. And, turn off the power and water supply.

Get OEM Whirlpool Dishwasher Parts from PartsIPS.

Before starting the Whirlpool dishwasher installation process, we will check what are the tools and supplies required.


Cordless drill, adjustable wrench, socket wrench, level, screwdrivers, pliers, measuring tape, utility knife, parts included with your machine and additional tools if any listed in the manual's installation instructions.


Towel or large of cardboard, shallow pan/ bucket, flashlight, power cord and water line installation kit.

Whirlpool Dishwasher Installation Process

Here, you can check the complete process for your Whirlpool dishwasher installation.

Measure Dishwasher Dimensions

While installing a new dishwasher in your kitchen, you will need to ensure that you have the right cabinet opening dimensions. So, make sure you measure the cabinet opening's width, height and depth to ensure the right fit for your dishwasher.

Prepare the New Dishwasher for Installation

Now, you have to open the cardboard box that your machine delivered in and remove shipping materials. Keep aside the cardboard as it may be used while installing the dishwasher.

Open the door of the dishwasher and remove any styrofoam or wrap from the interior. Keep aside parts or tools if any packaged separately inside the cardboard box.

Next, tilt the machine on its back with the help of another person. Then, you have to remove the front access panel of the dishwasher. If your model has a drip tray, you will need to disconnect the tray sensors. After that, route the power cord through the terminal box. Check the instructions given in the manual for connecting remaining wires and complete it.

After completion of the electrical wires connecting, attach the drain hose to the drain port. Route the drain hose as well as power cord underneath the rear legs of the machine.

Whirlpool Replacement Parts for Dishwashers - Shop Online!

Attach Water Supply to the Dishwasher

Attach the 90-degree elbow fitting onto the water supply line. After that, connect the fill hose to the valve located on the bottom of the appliance and tighten by hand and then tighten an additional 1/4 to 1/2 turn with pliers.

You should not use Teflon tape or thread sealer on the water valve threads. Ensure that the rubber washer is present inside the water hose fitting. Connect the water supply line to the dishwasher's back.

Next, you have to go through the water hose connection. While connecting this, ensure it is looped up and over an arch. You can use the handy U-bend that is supplied with the appliance to connect this hose. Leave the hose end as high as possible in the drain pipe. And, clamp the hose down.

Level & Adjust the Height of Dishwasher

Measure the cabinet opening height and adjust the appliance's rear leveling legs. Make sure height should be matched. Test with a level to ensure leveling legs of the dishwasher are even. Every dishwasher requires level placement for proper water drainage.

Place the Whirlpool Dishwasher into Cabinet Opening

Once you confirmed the dishwasher is leveled correctly, tilt it upright onto cardboard and move towards the required location. Then, connect the drain hose, power cord and water supply line through the sink cabinet. Secure slack in the drain hose to the backside of the cabinet under the sink to avoid backwash. The hose should be higher than the drain inlet. After that, slide the machine into the cabinet opening.

Once your dishwasher is in place, you have to readjust the feet to make sure it is level and stable.

Reliable and High-Quality Whirlpool Dishwasher Replacement Parts - Buy Now!

Secure the Unit to Cabinets and Countertops

You have to connect the anchor brackets to the top of the washer collar on the left and right sides. Then, slide it back until the exterior is flush with the surrounding cabinet doors. Now, take a level and measure the levelness of the cabinet with the top edge of the appliance. Adjust the front-level legs as needed. Once it is leveled, you can screw in the anchor brackets to secure the unit in place.

Next, connect the water supply line to the hot water line as per your model manual's instructions. Turn on the water at the shut-off valve. Also, attach the drain hose to the drain port. Finally, plug in the power cord.

Run a Test Cycle

Run a test cycle on your new Whirlpool dishwasher and inspect for leaks & other operational issues. If everything is good in its test cycle, place the front access panel.

Final Words

That's all about our instructions on how to install Whirlpool dishwasher. However, these instructions may vary by model. So, you should refer to your dishwasher's manual before starting yourself.
